DRYTEN [OPTION] COVER UNDER (OPTION) WATER TAP ADAPTER INLET HOSE
HOSE DRAIN [FOR PUMP] HOSE DRAIN[FOR NONPUMP] CONNECTOR INLET [OPTION]
2. STRUCTURE OF THE WASHING MACHINE
3
STRUCTURE
• HOSE DRAIN
• POWER CORD
• LINT FILTER(2EA)
• HOT WATER TAP
• COLD WATER TAP
After using the washer,
close the water tap, In case
of the single valve model,
there is no hot water valve.
After using the washer,
close the water tap
• CASE DETERGENT
AND SOFTENER
• BLEACH INLET
• ADJUSTABLE LEG
• PULSATOR
• CONTROL PANEL
Accessories (Full Option)
The parts and features of your washer are illustrated on this page.
Become familiar with all parts and features before using your washer.
NOTE
• The drawings in this book may vary from your washer model.
They are designed to show the different features of all models covered by this book,
Your model may not include all features.
DRYTEN
