Daewoo DWF-800MP - Water Connection

6
1 Pull down the collar of the
inlet hose to separate it from
the hose adapter.
4 Remove the tape, and
screw connector B into
connector A tightly.
2 Loosen the four screws
properly in fitting into water
tap.
5 Connect the inlet hose to
the hose adapter, pulling
down the collar of hose end.
3 Fit the hose adapter into the water
tap and tighten the four screws
evenly while pushing up the
adapter so that the rubber packing
can stick to the water tap tightly.
6 Connect the opposite end of
the hose to water inlet of
your washer tightly.
• Please check the rubber
packing is inside the hose
end.
TAPE
Connector B
Connector A
1 Connect the inlet
hose to the
thread of water
tap or water pipe
by tightening.
2 For the opposite
end, connect it
to water inlet as
the above
procedure 6.
Inlet Hose
Connector D
Rubber
Packing
Connector C
WATER CONNECTION
Be careful not to confuse hot water inlet (pink color) and cold water inlet (blue color), if your
washer is provided with dual water inlets.
Also if you have only one water tap, connect the inlet hose with cold water inlet (blue color).
For normal tap
❐ In case that your washer is not provided with collar compartment, procedure 3 and 5 is
not necessary.
For Thread-Fitting Type
Leak Test
Turn on the water completely to check for any leakage. If any leakage, turn off the water, try
again as the above procedures.
For the special tap, call a qualified plumber for the installation.
Connector
Connector Hose
connector A
connector B
TAPE
