Daewoo DWF-802 - Installation Instructions; Location of Washer; Drain System

DRYTEN(OPTION) HOSE ADAPTER UNDER COVER(OPTION)
INLET HOSE(OPTION)
HOSE CONNECTOR(OPTION)
CONNECTOR INLET(OPTION)
2. STRUCTURE OF THE WASHING MACHINE
3
STRUCTURE
• GROUND WIRE
In case of 3-wire
power cord, ground
wire will not be
provided
• POWER CORD
• DRAIN HOSE
• LINT FILTER
• COLD WATER TAP
After using the washer,
close the water tap
• DETERGENT CASE
• ADJUSTABLE LEG
• SOFTENER INLET
• BLEACH INLET
• CONTROL PANEL
• POWER SWITCH
• PULSATOR
• HOT WATER TAP
After using the washer, close the water tap.
In case of the single valve model,
there is no hot water valve.
UP
The parts and features of your washer are illustrated on this page.
Become familiar with all parts and features before using your washer.
NOTE
• The drawing in this book may vary from your washer model. They are designed to show the different fea-
tures of all models covered by this book, Your model may not include all features.
• Page references are included next to same features.
Refer to those pages for more information about the features.
DRAIN HOSE
In case of screw shaped inlet hoses
water tap adapters will not be provided.
NON PUMP MODEL PUMP MODEL
■
Accessories
