Service Manual
Service Manual
5. Chassis Layout and Overall Wiring Diagrams
5.1 E2019B Major Part Bom
N Parent Nombel Material Description
1 7.11.SP104804A0LK1 B/T Adapter(Power Boadr) LEKE, LK-SP104804A,ROHS
2 7.15.TRSC88A000CV2 Main Board CVT, T.RSC8.8A, ATSC, ROHS
3 1.18.LED185CMB3LA1 LCD Panel CMO，M185B3-LA1 ， ROHS
4 1.22.02SJ103308142 Speaker SJX,SJ-1003230, 4Ω/5W, ROHS
5 7.05.E2032B0000002 Key Board E2032B,ROHS
6 7.04.C2019B0000001 IR LED Board C2019B,ROHS
7 7.11.LE190103F0LK1 INVERTER(恒流板) LEKE, LK-LE190103F,ROHS
5.2 E2022B Major Part Bom
N Parent Nombel Material Description
1 7.11.SP104804A0LK1 B/T Adapter(Power Boadr) LEKE, LK-SP104804A,ROHS
2 7.15.TRSC88A000CV2 Main Board CVT, T.RSC8.8A, ATSC, ROHS
3 1.18.LED215AUHW010 LCD Panel AUO,M215HW01 VB,1920x1080, ROHS
4 1.22.02SJ103308142 Speaker SJX,SJ-1003230, 4Ω/5W, ROHS
5 7.05.E2032B0000002 Key Board E2032B,ROHS
6 7.04.C2019B0000001 IR LED Board C2019B,ROHS
7 7.11.HQLED22L00HQ1 INVERTER( 恒流板) HQ-LED22L,ROHS
5.3 E2024B Major Part Bom
N Parent Nombel Material Description
1 7.11.SP104804A0LK1 B/T Adapter(Power Boadr) LEKE, LK-SP104804A,ROHS
2 7.15.TRSC88A000CV2 Main Board CVT, T.RSC8.8A, ATSC, ROHS
3 1.18.LED236CMH1LE2 LCD Panel CMO, V236H1-LE2, 1920*1080,ROHS
4 1.22.02SJ103308142 Speaker SJX,SJ-1003230, 4Ω/5W, ROHS
5 7.05.E2032B0000002 Key Board E2032B,ROHS
6 7.04.C2019B0000001 IR LED Board C2019B,ROHS
7 7.11.HQLED07K00HQ1 INVERTER(恒流板) HQ-LED07K, ROHS(自带 350 mm FFC线)
