4
SUPER
MODE 5
Press TEMP. CONTROL button and make 5 led lamp on.
ON POINT : 2.0°C
OFF POINT : -3.0°C
5
FREEZER
OK / NG
DISPLAY
1) Initial Condition : FREEZER RED LED LAMP on
2) OK Condition : If temperature goes down under -5°C, green led lamp is supposed to
be on.
3) NG Condition : If temperature condition or time condition is satisfied, red led lamp
is on.
– Temperature Condition : Over -5°C at D-SENSOR when Comp turns off.
– Time Condition : Over -5°C at D SENSOR when Comp. Is running for 4hr.
4) D1 ERROR : FREEZER RED LED LAMP - on & off
(This error means that D-SENSOR is short or open condition.)
5) D2 ERROR : FREEZER RED LED LAMP - on & off two times
(D2 ERRORhappens when HEATER or TEMP. FUSE is open or there
is heavy frost on the surface of EVA. On this condition, the system
will be in defrost mode for 80 min.)
6
REFRIGERATOR
OK / NG
DISPLAY
1) Initial Condition : FREEZER RED LED LAMP on
2) OK Condition : If temperature goes down under 10°C, green led lamp is supposed to
be on.
3) NG Condition : If temperature condition or time condition is satisfied, red led lamp
is on.
– Temperature Condition : Under -7°C or over 10°C at D-SENSOR when Comp
turns off.
– Time Condition : Over 10°C at D SENSOR when Comp. Is running for 4hr.
4) R1 ERROR : REFRIGERATOR RED LED LAMP - on & off
(This error means that R-SENSOR is short or open condition.)
7
DETERMINATION
OF
DEFROST
1) Starting condition of Defrost Mode
•
When accumulated running time of comp. is 6, 8, 12, 30hrs.
k
After Checking the condition ‘
•
’ if total time(COMP on time + COMP off time)
is more than 24, 48, 75hrs, then defrost mode starts immediately.
Accumulated running time of
COMP
Total running time of COMP
RT-SENSOR
Door Open Door Close Door Open Door Close
RT 33°C-
8HR 8HR 24HR 24HR
18<RT< 32°C 12HR 30HR 48HR 75HR
15<RT< 17°C 6HR 6HR 24HR 24HR
RT 14°C-
6HR 6HR 24HR 24HR
Daewoo Electronics 46
