Daewoo ERF-36.A..EU - Page 49

16
R OFF POINT
OPTION
1) R-SENSOR OFF POINT can be adjusted by changing the input voltage of MICOM 8
pin.
2) The default of input voltage is 0V.
3) The changed OFF POINT is base OFF POINT + OFF POINT of input voltage.
MICOM
R42
R43
J2
8 PIN
R41R41
CC16CC16
4) The change of R-SENSOR OFF POINT depend on the input voltage of MICOM
5) APPLICATION (MAIN PCB)
• Default : MICOM8 PORT – 0V
k Change of R OFF POINT 1.0 deg - : changing R42, R43 after deleting J2
EX) •delete J2 kR42 : 10 K
Ω
l R43 : 10 K
Ω
MICOM
Input (V)
0 1.0 1.5 2.0 2.5 3.7 5.0
OFF
POINT
Variation
(- )
0-
(DEF)
1.0- 2.0- 3.0- 1.0
−
2.0
−
3.0
−
R42, 43
(K
Ω
)
J2
(in use)
R42 : 40
R43 : 10
R42 : 23.3
R43 : 10
R42 : 15
R43 : 10
R42 : 10
R43 : 10
R42 : 3.5
R43 : 10
R42 : 10
R43 : DEL
49 Daewoo Electronics
