NO PART NAME PART CODE MODEL DESCRIPTION REMARK
4. Parts list (ERF-384A)
PART LIST
1 SHELF R 3017823200 3 GPPS 394/414
2 COVER VEGTB CASE 3011453600 1 GPPS
3 CASE VEGTB 3011163480 2 GPPS
4 CASE ICING 3011163200 1 PP
5 CASE FD 3011115940 1 HIPS
6 CASE FC 3011115410 2 HIPS
7 CASE FA 3011115230 1 HIPS
8 PLATE SHELF GLASS 3014547700 3 GLASS t4.0 OPTION
9 FRAME GLASS SHELF 3012202400 3 HIPS OPTION
10 PLATE V/CASE COVER GLASS 3014547800 1 GLASS t4.0 OPTION
11 FRAME V/CASE COVER 3012202600 1 HIPS OPTION
12 BASE CONTROL PANEL COLOUR PAGE 42 1 HIPS
13 CABLE TIE 4016N03281 1
14 PCB MAIN AS 30143A5060 1
15 HARNESS F PCB 3012718300
16 PCB F AS 3014372130 1
17 WINDOWS LED 3015507400 1 SILICON RUBBER
18 PANEL CONTROL COLOUR PAGE 42 1 ABS
19 SWITCH LAMP 3018111500 1 250V 0,25A
20 WINDOW C/PANEL L/L 3015507200 ABS
21 SOCKET LAMP AS 3017903900 1 ASSY
22 COVER MULTI DUCT 3011451910 1 HIPS
23 INSULATOR MULTI DUCT 3016637000 1 F-PS
24 LAMP 3013600700 1 230V 15W
25 WINDOW LAMP 3015503300 1 GPPS
26 SENSOR R AS 3012731800 1
27 EVAPORATOR AS 3017045600 1 EVA+SUC PIPE
28 HEATER D AS 3012807600 1 GLASS HEATER+FUSE TEMP
29 BRACKET FAN MOTOR 3010615600 1 PP
30 MOTOR FAN AS 3011804710 1 DAI-6122DESPA
31 LOUVER F B 3018905600 1 HIPS
32 FAN 3011801410 1 ABS
33 FIXTURE FAN RING 3012005400 1 SUS304 t0.5
34 LOUVER F A 3018913900 - HIPS
35 BUSHING FAN MOTOR 3010901800 2 NR
36 ASSY CAB URT 3010071001 1 ASSY
37 HINGE *T 3012908100 2 P/O+ZN t3.2
38 SPECIAL BOLT C 3016004900 10 M5xP0.89xL16 SWCH22A
39 CAP SCREW COLOUR PAGE 42 1 PE-LD
40 CAP SCREW HOLE 3010920300 1 HIPS
41 SPECIAL WASHER HINGE 3016005500 3 S20C t1.0 13/7
42 SHAFT HI 3014903200 2
43 HINGE *M 3012908001 1 DIE CASTING
44 HINGE *U 3012908201 2 P/O+ZN t3.2
45 COVER CAB BRACKET COLOUR PAGE 42 1 HIPS
46 FOOT ADJUSTING AS 3012101800 2 PP+SPECIAL BOLT
47 CAP DRAIN HOSE 3010919700 1 NBR
48 CASE VAPORY 3011162600 1 PP
9 FIXTURE COMP 3012005300 2 SK5+ZN5-C t0.8
50 DRYER ASSY 3016802202 1 15Gr (t0.51)
51 ABSORBER COMP 3010101700 4 NR
52 BASE COMP 3010318600 1 SBHG t1.0
53 SPECIAL SCREW A 3016004300 4 M6.5xL20
54 CAPACITOR RUN 3016402110 1 5uF
55 SPECIAL WASHER R/C 3016006410 1
56 SPECIAL NUT R/C 3016006510 1 M8
57 SCREW MACHINE 7051401065 2 PAN 4x10 BSNI
