7. Part list (ERF-367A/397A/417A Type)
PART LIST
NO PART NAME PART CODE MODEL DESCRIPTION REMARK
367 397 417
1 PLATE SHELF GLASS 3014547700 3 4 4 GLASS t4.0 OPTION
2 PLATE V/CASE COVER GLASS 3014547800 1 1 1 GLASS t4.0 OPTION
3 FRAME GLASS SHELF 3012202400 3 3 3 HIPS OPTION
4 FRAME C/CASE COVER 3012202500 1 1 1 HIPS OPTION
5 FRAME V/CASE COVER 3012202600 1 1 1 HIPS OPTION
6 CASE CHILD 3011163340 - 1 1 GPPS
7 CASE VEGTB 3011163480 2 2 2 GPPS
8 CASE ICING 3011163200 1 1 1 PP
CASE FD 3011115940 1 1 1 HIPS
9 CASE FB (417:CASE FC) 3011115301 2 2 - HIPS
10 3011115410 - - 2 HIPS
11 CASE FA 3011115230 1 1 1 HIPS
12 SHELF R 3017823200 3 3 3 GPPS 394/414
13 COVER CHILLED CASE 3011453400 - 1 1 GPPS
14 COVER VEGTB CASE 3011453600 1 1 1 GPPS
15 BASE CONTROL PANEL COLOUR PAGE 52 1 1 1 HIPS
16 CABLE TIE 4016N03281 1 1 1
17 PCB MAIN AS 30143A3060 1 1 1
18 DOWN TRANS AS 5EPK041010 1 1 1
19 HARNESS F PCB 3012718310 1 1 1
20 PCB F AS 30143A3160 1 1 1
21 PANEL CONTROL COLOUR PAGE 52 1 1 1 ABS
22 SWITCH LAMP 3018111500 1 1 1 250V 0,25A
23 WINDOW C/P C/L 3015507100 1 1 1 ABS
24 SOCKET LAMP AS 3017903900 1 1 1 AC250V
25 COVER MULTI DUCT 3011451900 1 - - HIPS ASSY
3011452100 - 1 1 HIPS
26 INSULATOR MULTI DUCT 3016637000 1 - - F-PS
3013337200 - 1 1 F-PS
27 LAMP 3013600700 1 1 1 230V 15W
28 WINDOW LAMP 3015503300 1 1 1
29 SENSOR R AS 3012731800 1 1 1 GPPS
30 EVAPORATOR AS 3017045600 1 1 1 EVA+SUC PIPE
31 HEATER D AS 3012807600 1 1 1 GLASS HEATER+FUSE TEMP
32 BRACKET FAN MOTOR 3010615600 1 1 1 PP
33 MOTOR FAN AS 3011804710 1 1 1 IS-231 1DWBF0
34 LOUVER F B 3018905500 1 1 - PP
3018905600 - - 1 PP (417:HIPS)
35 FAN 3011801410 1 1 1 ABS /100
36 FIXTURE FAN RING 3012005400 1 - - SUS304 t0.5
37 LOUVER F A 3018913800 1 1 - HIPS
3018913900 - - 1 HIPS
38 BUSHING FAN MOTOR 3010901800 2 2 2 NR
39 ASSY CAB URT 3010071001 1 - - ASSY
3010071010 - 1 - ASSY
3010071020 - - 1 ASSY
40 HINGE *T 3012908100 2 2 2 P/O+ZN t3.2
41 SPECIAL BOLT C 3016004900 10 10 10 M5xP0.89xL16 SWCH22A
42 CAP SCREW COLOUR PAGE 52 1 1 1 PE-LD
43 CAP SCREW HOLE 3010920300 1 1 1 HIPS
44 SPECIAL WASHER HINGE 3016005500 3 3 3 S20C t1.0 13/7
45 SHAFT HI 3014903200 2 2 2
46 HINGE *M 3012908001 1 1 1 DIE CASTING
47 HINGE *U 3012908201 2 2 2 P/O+ZN t3.2
48 COVER CAB BRACKET COLOUR PAGE 52 1 1 1 HIPS
49 FOOT ADJUSTING AS 3012101800 2 2 2 PP+SPECIAL BOLT
50 CAP DRAIN HOSE 3010919700 1 1 1 NBR
51 CASE VAPORY 3011162600 1 1 1 PP
