Tornado Cylinder 700W Cyclonic Vacuum
Model No.: FLR00046
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Assembling Your Vacuum Cleaner
CAUTION Ensure that the vacuum cleaner is not connected to the mains supply
before using the attachments.
Attaching the Flexible Hose (14) to the Vacuum Cleaner
Attach the Flexible Hose (14) onto the vacuum cleaner by pushing the Hose
Connector (15) into the Air Intake (11) and rotating anticlockwise, arrowed
below:
To remove the hose, rotate the Hose Connector (15) clockwise and pull out.
Attaching the Telescopic Tube (18) and Floor Tool (12)
1. Push the Tool connector (17) into the top of the Telescopic Tube (18) as shown
below:
2. Extend the Telescopic Tube (18) to the desired length by pushing the catch
down and extending.
3. Attach the Floor Tool (12) to the other end as shown above.
Tool Connector (17)
Telescopic Tube (18)
Floor Tool (12)
Flexible Hose (14)
