HOW TO Disassemble / Assemble for each part
9. Pump (Dispenser / Ice Maker)
1) Disassembling Procedure
No No
Procedure Procedure
15
Pull out the water tank Unscrew 2 points with (+) driver
After Turning on water icon lamp , Press Pull both locker and Separate the cover
First, Remove the cover on the right.
26
button to drain water in the tube. on the left with thin driver.
37
Pull out the vegetable case and shelf Disconnect the pump wire housing(2Points)
48
Dispenser pump
Ice maker pump
Holder
(No need driver) Separate pump from holder made by silicon
30
To Next Page
