17
4) Output Control and Limit Time of each Defrosting mode
2. Forced Defrosting
1) Start : Defrosting starts by pressing Temp. control s/w
five times in a row when door is open.
2) End : No function
3) Process : using Heater
4) Defrosting mode and procedure : same as Normal
Defrosting ( Skip pre-cool mode )
5) Heater is On during initial 30 seconds without concerning
D-sensor Temp.
5 Initial
Defrosting
COMP
F-FAN
HTR
1. If D-sensor temp.= 3.5 in the initial power
input, normal defrosting mode begins without
concerning Comp run-time
( include Pre-cool mode )
2. Defrosting begins after doing Comp restart-
prevention function with dealy for six min.
in initial defrosting mode.
3. Comp will be On immediately if D-sensor
temp. =3.5 in initial power input.
( No dealy for six min. )
6 Prevention
of Comp
COMP
F-FAN
1. In order to protect Comp after Comp off,
it won't re-start for six min. though
R-sensor becomes On.
NO CONTROL FUNCTION CONTROL OBJECTS CONTENTS REMARK
OPERATION AND FUCTIOLNS
C
C
To Next Page
