DISASSEMBLY AND ASSEMBLY
If there is COVER F LAMP on the ceiling, you must take off it first. In case there's NOT, you should follow how to remove
LOUVER F section.
1) COVER F LAMP DISASSEMBLY
At first, take off WINDOW LAMP.
Turn the LAMP to the left and remove it.
Using (+) screw driver, unfasten the screw
in the center of COVER F LAMP.
With force, pull the COVER downwards
to remove it.
1
2
3
4
To Next Page
