Daewoo FR-4502K - Model Parts Lists

38
EXPLODED VIEW AND PARTS LIST
1. TOTAL PARTS LIST (FR-4501K)
PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
3010031200 ASSY CAB URT FRM(P)-371 1
3012911500 HINGE*T SPCC T2 1
3012905400 SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
3011449800 COVER *T HI HIPS 1
7112401211 SCREW TAPPING T1TRS 4X12 MFZN 1
3012911400 HINGE *M AS DC-2 ZN 1
FOOT ADJUST AS 2
3012911300 HINGE *U AS SPHC-H T4 1
3012905400 SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
3011450200 COVER CAB BRKT PP 1
7112401211 SCREW TAPPING T1TRS 4X12 MFZN 2
3010103700 ABSORBER SUC P NR 1
3011302012 CORD POWER AS 1 250V/16A
7112401211 SCREW TAPPING T1TRS 4X12 MFZN 1
7001400865 SCREW MACHINE PAN 4X8 BSNI 1
3013202700 HOSE DRN B PP 1
3012405800 GRILLE SBHG1 1
7112401211 SCREW TAPPING T1TRS 4X12 MFZN 5
3016805500 DRYER AS 1
3014433500 PIPE WICON TSW 1
OD4.76XT0.7XL14560
3011200400 CLAMP FAN SUS304 1
3011800400 FAN 1
MOTOR C 1
3012004400 FIXTURE C MOTR SUS 1
3010102100 ABSORBER C MOTR NR,FRB-5350NT 1
3011161900 CASE VAPORI PP 1
7112401211 SCREW TAPPING T1TRS 4X12 MFZN 2
COMPRESSOR 1
3018116610 SWITCH P-RELAY AS 1
3012610000 CLAMP BRAND SK-5 T0.7 1
RELAY
3010318400 BASE COMP SBHG1 1
3016500000 CASTER *B PP OD36XL37 2
3014902900 SHAFT CASTER *B SPH, T1, OD6XL51 2
3016003300 SPECIAL BOLT T2 M6.5X20 4
3012007900 FIXTURE MOTR B PP 1
MOTOR F 1
3011802200 FAN ABS(OD110) 1
7112401211 SCREW TAPPING T1TRS 4X12 MFZN 2
3013336310 INSU F LUVR EPS 1
3013402600 KNOB F CONTL PP 1
3018910400 LOUVER F HIPS 1
7112401611 SCREW TAPPING T1TRS 4X16 MFZN 2
3010924600 CAP F-LUVR HIPS T2.3 2
3017821600 SHELF F HIPS T3.0 1
Caution
7112401208 SCREW TAPPING T1 TRS 4X10 SUS 1
3012509800 GUIDE TWIST ICE HIPS 1
3013002300 HOLDER ICE SAS HIPS 1
3012201900 FRAME ICE CASE 1
SAS
PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
BOX ICE 1
3018100050 SWITCH DR DSD-5(220V) 1
3010936100 CAP DV *M HI HOLE ABS 1
3017903610 SOCKET R LAMP AS ¡¡ 1
3013600080 LAMP AS 240V/15W 1
7121300811 SCREW TAPPING T2 PAN 3X8 MFZN 1
3013402500 KNOB R CONTL ABS 1
3011449900 COVER R CONTL BOX HIPS 1
3012733700 HARNESS R-THERMO 1
AS
3018301500 THERMOSTAT GNF-175D 1
3015505200 WINDOW LAMP PP 1
3011439500 COVER CUBIC HIPS 4
3017460900 INSU R *S *L F-PS 1
3018910200 LOUVER R *S *L PP 1
3017461000 INSU R *S *R F-PS 1
3018910300 LOUVER R *S *R PP 1
3017821800 SHELF CHILD GPPS 1
3011162300 CASE CHILD GPPS 1
3017822000 SHELF R GPPS 1
3011451400 COVER VEGETB GPPS 1
3011162400 CASE VEGETB GPPS 1
3013336000 INSULATOR F A EPS 1
3012509900 GUIDE DRN AL 0.4T 1
3014433400 PIPE DRN AL 1.0T 1
3012009400 FIXTURE R CONTL PP 1
COVR
3013336100 INSULATOR F B EPS 1
ASSY F DR 1
3011450400 COVER CAP HOLE B PP 1
3011450500 COVER T HI HRNS *L PP 1
7112401211 SCREW TAPPING T1TRS 4X12 MFZN 1
3012301420 GASKET F DR AS PVC 1
3019013500 POCKET F HIPS 2
ASSY R DR 1
3011450300 COVER CAP HOLE A PP 1
3012301720 GASKET R DR AS PVC 1
3011451200 COVER DARIY ROOM GPPS 1
3019012900 POCKET DAIRY HIPS 1
3011162100 CASE EGG GPPS 1
PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
