RXPLODED VIEW AND PARTS LIST
3013336310 INSU F LUVR EPS 1
3013402600 KNOB F CONTL PP 1
3018910400 LOUVER F HIPS 1
7112401611 SCREW TAPPING T1TRS 4X16 MFZN 2
3010924600 CAP F-LUVR HIPS T2.3 2
3017821600 SHELF F HIPS T3.0 1
3013002300 HOLDER ICE SAS HIPS 1
3012201900 FRAME ICE CASE SAS 1
BOX ICE 1
3012509800 GUIDE TWIST ICE HIPS 1
7112401208 SCREW TAPPING T1 TRS 4X10 SUS 1
3018100050 SWITCH DR DSD-5(220V) 1
3010936100 CAP DV *M HI HOLE ABS 1
3011450100 COVER R LAMP HIPS 1
3017903610 SOCKET R LAMP AS 1
3013600080 LAMP AS 240V/15W 1
7121300811 SCREW TAPPING T2 PAN 3X8 MFZN 1
3015505200 WINDOW LAMP PP 1
3011439500 COVER CUBIC HIPS 2
3017460900 INSU R *S *L F-PS 1
3018910200 LOUVER R *S *L PP 1
3017461000 INSU R *S *R F-PS 1
3018910300 LOUVER R *S *R PP 1
3017821800 SHELF CHILD GPPS 1
3011162300 CASE CHILD GPPS 1
3017822000 SHELF R GPPS 1
3011451400 COVER VEGETB GPPS 1
3011162500 CASE VEGETB GPPS 2
3013336000 INSULATOR F A EPS 1
3012509900 GUIDE DRN AL 0.4T 1
3014433400 PIPE DRN AL 1.0T 1
3012009400 FIXTURE R CONTL PP 1
COVR
3013336100 INSULATOR F B EPS 1
ASSY F DR 1
301550530 WINDOW FCP GPPS 1
SCREW TAPPING 1
3014228600 PANEL CONTROL F ABS 1
3014228600 PCB FRONT AS T1.6 1
7121300811 SCREW TAPPING T2 PAN 3X8 MFZN 1
3011450400 COVER CAP HOLE B PP 1
3011450500 COVER T HI HRNS *L PP 1
7112401211 SCREW TAPPING T1TRS 4X12 MFZN 1
3012301420 GASKET F DR AS PVC 1
3019013500 POCKET F HIPS 2
3011450300 COVER CAP HOLE A PP 1
PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
ASSY R DR 1
3012301720 GASKET R DR AS PVC 1
3011451300 COVER DARIY ROOM GPPS 1
3019013000 POCKET DAIRY HIPS 1
3011162100 CASE EGG GPPS 1
3019013100 POCKET SMALL HIPS 3
3012509600 GUIDE POCKET HIPS 1
3019013300 POCKET JUMBO HIPS 1
3019013400 POCKET BOTTLE HIPS 1
PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
To Next Page
