42
3011451300COVER DARIY ROOMGPPS 1
3019013000POCKET DAIRY HIPS 1
3011162100CASE EGG GPPS 1
3019013100POCKET SMALL HIPS 3
3012509600GUIDE POCKET HIPS 1
3019013300POCKET JUMBO HIPS 1
3019013400POCKET BOTTLE HIPS 1
PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
4. TOTAL PARTS LIST (FR-4502N)
PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
3010031200ASSY CAB URT FRM(P)-371 1
3012911500HINGE*T SPCC T2 1
3012905400SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
3011449800COVER *T HI HIPS 1
3011449500COVER GUIDE L/WIREPP 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 1
3010519800BOX MAIN POWER PP 1
PCB MAIN AS PP 1
HARNESS RUN CON 1
COVER M-PCB BOX PP 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 2
3012911400HINGE *M AS DC-2 ZN 1
3016001220SPECIAL BOLT M 6X20 SWCH22A(WH) 2
FOOT ADJUST AS 2
3012911300HINGE *U AS SPHC-H T4 1
3012905400SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
3011450200COVER CAB BRKT PP 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 2
3010103700ABSORBER SUC P NR 1
3011302012CORD POWER AS 1 250V/16A
7112401211SCREW TAPPING T1TRS 4X12 MFZN 1
7001400865SCREW MACHINE PAN 4X8 BSNI 1
3013202700HOSE DRN B PP 1
3012405800GRILLE SBHG1 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 5
3016805500DRYER AS 1
3014433500PIPE WICON TSW 1
OD4.76XT0.7XL14560
3011200400CLAMP FAN SUS304 1
3011800400FAN 1
MOTOR C 1
3012004400FIXTURE C MOTR SUS 1
3010102100ABSORBER C MOTR NR,FRB-5350NT 1
3011161900CASE VAPORI PP 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 2
COMPRESSOR 1
3018116610SWITCH P-RELAY AS 1
3012610000CLAMP BRAND RELAYSK-5 T0.7 1
3010318400BASE COMP SBHG1 1
3016500000CASTER *B PP OD36XL37 2
3014902900SHAFT CASTER *B SPH, T1, OD6XL51 2
3016003300SPECIAL BOLT T2 M6.5X20 4
3012007900FIXTURE MOTR B PP 1
MOTOR F 1
3011802200FAN ABS(OD110) 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 2
RXPLODED VIEW AND PARTS LIST
