46
3011162200CASE ICE PP 1
BOX ICE 1
PART CODE PART NAME PART DESCRIPTIONQ'TYREMARK
3018100050SWITCH DR DSD-5(220V) 1
3010936100CAP DV *M HI HOLE ABS 1
3017903610SOCKET R LAMP AS 1
3013600080LAMP AS 240V/15W 1
7121300811SCREW TAPPING T2 PAN 3X8 MFZN 1
3013402500KNOB R CONTL ABS 1
3011449900COVER R CONTL BOXHIPS 1
3012733700HARNESS R-THERMO 1
3018301500THERMOSTAT GNF-175D 1
3015505200WINDOW LAMP PP 1
3011439500COVER CUBIC HIPS 2
3017460900INSU R *S *L F-PS 1
3018910200LOUVER R *S *L PP 1
3017461000INSU R *S *R F-PS 1
3018910300LOUVER R *S *R PP 1
3017821700SHELF R SWRM-B 2
3011451400COVER VEGETB GPPS 1
3011162400CASE VEGETB GPPS 1
3013336000INSULATOR F A EPS 1
3012509900GUIDE DRN AL 0.4T 1
3014433400PIPE DRN AL 1.0T 1
3012009400FIXTURE R CONTL PP 1
COVR
3013336100INSULATOR F B EPS 1
ASSY F DR 1
3011450400COVER CAP HOLE B PP 1
3011450500COVER T HI HRNS *L PP 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 1
3012301420GASKET F DR AS PVC 1
3019013500POCKET F HIPS 2
ASSY R DR 1
3011450300COVER CAP HOLE A PP 1
3012301720GASKET R DR AS PVC 1
3011451200COVER DARIY ROOMGPPS 1
3019012900POCKET DAIRY HIPS 1
3011162100CASE EGG GPPS 1
3019013200POCKET MULTI HIPS 1
3012509600GUIDE POCKET HIPS 1
3019013300POCKET JUMBO HIPS 1
3019013400POCKET BOTTLE HIPS 1
PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
7. TOTAL PARTS LIST (FR-4505K)
PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
3010031200ASSY CAB URT FRM(P)-371 1
3012911500HINGE*T SPCC T2 1
3012905400SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
3011449800COVER *T HI HIPS 1
3012911400HINGE *M AS DC-2 ZN 1
3016001220SPECIAL BOLT M 6X20 SWCH22A(WH) 2
FOOT ADJUST AS 2
3012911300HINGE *U AS SPHC-H T4 1
3012905400SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
3011450200COVER CAB BRKT PP 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 2
3010103700ABSORBER SUC P NR 1
3011302012CORD POWER AS 1 250V/16A
7112401211SCREW TAPPING T1TRS 4X12 MFZN 1
7001400865SCREW MACHINE PAN 4X8 BSNI 1
3013202700HOSE DRN B PP 1
3012405800GRILLE SBHG1 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 5
3016805500DRYER AS 1
3014433500PIPE WICON TSW 1
OD4.76XT0.7XL14560
3011200400CLAMP FAN SUS304 1
3011800400FAN 1
MOTOR C 1
3012004400FIXTURE C MOTR SUS 1
3010102100ABSORBER C MOTR NR,FRB-5350NT 1
3011161900CASE VAPORI PP 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 2
COMPRESSOR 1
3018116610SWITCH P-RELAY AS 1
3012610000CLAMP BRAND RELAYSK-5 T0.7 1
3010318400BASE COMP SBHG1 1
3016500000CASTER *B PP OD36XL37 2
3014902900SHAFT CASTER *B SPH, T1, OD6XL51 2
3016003300SPECIAL BOLT T2 M6.5X20 4
3012007900FIXTURE MOTR B PP 1
MOTOR F 1
3011802200FAN ABS(OD110) 1
7112401211SCREW TAPPING T1TRS 4X12 MFZN 2
3013336310INSU F LUVR EPS 1
3013402600KNOB F CONTL PP 1
3018910400LOUVER F HIPS 1
7112401611SCREW TAPPING T1TRS 4X16 MFZN 2
3010924600CAP F-LUVR HIPS T2.3 2
3017821600SHELF F HIPS T3.0 1
3012509700GUIDE ICE CASE HIPS 1
RXPLODED VIEW AND PARTS LIST
