24
DIAGRAM
3. AIR FLOW DIAGRAM
Multiple outlet of cooling air
Please don’t put in vegetable etc.
which contain moisture.
It might be frozen because of low temperature.
FREZER
Pleose don’t put bottles
sucfh as beer beverage etc.
It might be blown out because of freezing.
Inlet of cooling air
It should not be blocked with food etc.
as it is the inlet where cooling air returns.
To Next Page
