39
EXPLODED VIEW AND PARTS LIST
2. TOTAL PARTS LIST
1) FR-4501K(In case of NO. 75,81 refer to 42page)
NO PART CODE PART NAME PART DESCRIPTION Q'TY REMARK
1 3010031200 ASSY CAB URT FRM(P)-371 1
2 3012911500 HINGE*T SPCC T2 1
3 3012905400 SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
4 3011449800 COVER *T HI HIPS 1
5 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 1
6 3012911400 HINGE *M AS DC-2 ZN 1
7 3012101300 FOOT ADJUST AS PP 2
8 3012911300 HINGE *U AS SPHC-H T4 1
9 3012905400 SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
10 3011450200 COVER CAB BRKT PP 1
11 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 2
12 3010103700 ABSORBER SUC P NR 1
13 3011302012 CORD POWER AS 1 250V/16A
14 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 1
15 7001400865 SCREW MACHINE PAN 4X8 BSNI 1
16 3013202700 HOSE DRN B PP 1
17 3012405800 GRILLE SBHG1 1
18 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 5
19 3016805500 DRYER AS 1
20 3014433500 PIPE WICON TSW OD4.76XT0.7XL14560 1
21 3011200400 CLAMP FAN SUS304 1
22 3011800400 FAN 1
23 MOTOR C 1
24 3012004400 FIXTURE C MOTR SUS 1
25 3010102100 ABSORBER C MOTR "NR,FRB-5350NT" 1
26 3011161900 CASE VAPORI PP 1
27 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 2
28 COMPRESSOR 1
29 3018116610 SWITCH P-RELAY AS 1
30 3012610000 CLAMP BRAND RELAY SK-5 T0.7 1
31 3010318400 BASE COMP SBHG1 1
32 3016500000 CASTER *B PP OD36XL37 2
33 3014902900 SHAFT CASTER *B "SPH, T1, OD6XL51" 2
34 3016003300 SPECIAL BOLT T2 M6.5X20 4
35 3012007900 FIXTURE MOTR B PP 1
36 MOTOR F 1
37 3011802200 FAN ABS(OD110) 1
