5. Ice Maker (Dispenser Models Only)
1) Disassembling Procedure
HOW TO CHECK EACH PART
No No
Unscrew 3 points.
Remove 2 screws. Remove full ice sensor and level sensor.
27
Pull out the Ice Maker.
16
Procedure Procedure
Level Sensor
Full Ice
Sensor
510
Separate Cover I/M (A) from Cover I/M (B). Remove Ice sensor from Case Icing.
Check if ice droping motor is normal or not.
9
Separate Ice Maker from Frame Ice Maker. Remove 2 Pin housing ( Ice sensor )
Unscrew Fixture of Frame Ice Maker.
3
4
8
Drop Motor
34
