G424 Service Manual Base Engine Service Procedure168
6EN0626
6EN1919
E Sealant application to oil seal case.
Specified sealant: Silicone RTV sealant or equivalent.
NOTE:
1) Be sure to install the case quickly while the sealant is
wet(within 15 minutes).
2) After installation, keep the sealant area away front the oil
and coolant for approx. one hour.
F Rear plate installation
(1) Be sure install the spring washers and special washers in
correct position.
Seal ant
Spring
washer
Special washer
