Daewoo KOC-9Q4T Service Manual

3
MODEL KOC-9Q3T7S
POWER SUPPLY 230V~50Hz, SINGLE PHASE WITH EARTHING
MICROWAVE 1400W
POWER GRILL 1250W
CONSUMPTION CONVECTION 1250W
COMBINATION 2700W
MICROWAVE ENERGY OUTPUT 900W (IEC 705)
MICROWAVE FREQUENCY 2450MHz
OUTSIDE DIMENSIONS (W X D X H) 513X382X311mm(20.2X15X12.2 in.)
CAVITY DIMENSIONS (W X D X H) 354X341X231mm(13.9X13.4X9.1 in.)
NET WEIGHT Approx. 16.6Kg (46.6 lbs.)
TIMER 60 minutes
FUNCTION SELECTIONS Microwave / Grill / Convection / Combination
POWER SELECTIONS 10 LEVELS
CAVITY VOLUME 0.99 Cu. Ft
* SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE.
MODEL KOC-9Q4T
POWER SUPPLY 230V~50Hz, SINGLE PHASE WITH EARTHING
MICROWAVE 1400W
POWER GRILL 1250W
CONSUMPTION CONVECTION 1250W
COMBINATION 2700W
MICROWAVE ENERGY OUTPUT 900W (IEC 705)
MICROWAVE FREQUENCY 2450MHz
OUTSIDE DIMENSIONS (W X D X H) 513X383X311mm(20.2X15.1X12.2 in.)
CAVITY DIMENSIONS (W X D X H) 354X341X231mm(13.9X13.4X9.1 in.)
NET WEIGHT Approx. 16.6Kg (46.6 lbs.)
TIMER 60 minutes
FUNCTION SELECTIONS Microwave / Grill / Convection / Combination
POWER SELECTIONS 10 LEVELS
CAVITY VOLUME 0.99 Cu. Ft
* SPECIFICATION ARE SUBJECT TO CHANGE WITHOUT NOTICE.
2. SPECIFICATIONS

Daewoo KOC-9Q4T Specifications

General

Turntable	-
Control type	Buttons, Rotary
Display type	LED
Product color	Silver
Microwave power	1400 W
Built-in display	Yes
Appliance placement	Countertop
Number of power levels	10
Connected load	900 W
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	383 mm
Width	513 mm
Height	311 mm
Weight	16600 g
Interior dimensions (W x D x H)	354 x 341 x 231 mm
