TROUBLE SHOOTING GUIDE
( TROUBLE 4 )
The following visual conditions indicate a probable defective touch control circuit
1. Incomplete segments,
1) Segments missing.
2) Partical segments missing.
3) Digit flickering other than normal display slight
flickering.
4) “ : 0 ” does not display when power is on.
2. A distinct change in the diplay are not on when they
numbers is the display.
3. One or more digits in the diplay are not on when they should be.
4. Display indicates a number different from one setted.(For example, when 5:00 setted, 3:00 appears in the display.)
5. Specific numbers (for example 2 or 3) will not display when the knob is turned.
6. Display does not count down or up with time cooking or clock operation.
7. Oven is programmable and cooks normally but no display shows.
8. Display obviously jumps in time while counting down.
9. Display counts down noticeably too fast while cooking.
10. Display does not show the time of day when clear button is touched.
11. Oven lamp and turntable motor do not stop although cooking is finished. Check if the RELAY 2 contacts close if they are
close, replace touch control circuit.
