Daewoo KOR-866T - Specification


PRINTED CIRCUIT BOARD
3. P.C.B. LOCATION NO
(1) KOR-636T1S
NO NAME SYMBOL SPECIFICATION PART CODE Q'TY
1 BUZZER BZ1 BM-20K 3515600100 1
2 C ARRAY CA1 5P(6) 102 M 50V CN4XB-102M 1
3 CAPACITOR ELEC EC1,2 50V RSS 10uF CEXE1H100A 2
4 CAPACITOR ELEC EC3 50V RSS 470uF CEXF1H471V 1
5 CONNECTOR WAFER CN1 YW396-02AV 3519150520 1
6 CONNECTOR WAFER CN2 HLEM15S-1 4CW215SBD0 1
7 CONNECTOR WAFER CN3 YW396-05AV 3519150510 1
8 CONNECTOR WAFER CN101 HLEM15R-1 4CW215RBD0 1
9 DIODE SWITCH D1~4 1N4148 DZN4148--- 4
10 DIODE RECTIFY D6 ~ 11 1N4004A DZN4004A-- 6
11 DIODE ZENER ZD1 MTZ 3.9VB 1/2W DZUZ3R9BSB 1
12 DIODE ZENER ZD2 MTZ 20VB 1/2W DZUZ20BSB- 1
13 VFD DISPLAY DP1 SVM-5MS06 DSVM5MS06- 1
14 VFD HOLDER PP(BLACK) 3513002600 1
15 R ARRAY RA1 5P(4) 1/8 100K J RA-85X104J 1
16 RESISTOR R12 1/6W 1.2K 5% RD-AZ122J- 1
17 RESISTOR R2,6,9,18, 101, 102 1/6W 1K 5% RD-AZ102J- 6
18 RESISTOR R7,8 1/6W 47K 5% RD-AZ473J- 2
19 RESISTOR R3,10,11 1/6W 100 5% RD-AZ101J- 3
20 RESISTOR R1,4 1/6W 10K 5% RD-AZ103J- 2
21 RESISTOR R5 1/6W 1M 5% RD-AZ105J- 1
22 RESISTOR R103 1/4W 1K 5% RD-4Z102J- 1
23 RESISTOR R13 1/2W 56 5% RD-2Z560JS 1
24 RESISTOR R14,16,17 1/2W 200 5% RD-2Z201JS 3
25 RESISTOR R19 1/2W 1.2K 5% RD-2Z122JS 1
26 RESISTOR R15 1/2W 2K 5% RD-2Z202JS 1
27 REGULATOR VL1 MC7905C 1MC7905C-- 1
28 TRANSISTOR Q3 ~ 5 KRA-106M TZRA106M-- 3
29 TRANSISTOR Q1 KTA-1270Y TZTA1270Y- 1
30 TRANS POWER LVT1 DMR-814FS 5EPV035301 1
31 WIRE COPPER J1-J16 1/0.52 TIN COATING 85801052GY 19
32 CAPACITOR CERA C1~4,C6 104 50V Z AXIAL CCZF1H104Z 6
33 CAPACITOR CERA C5 473 50V Z AXIAL CCZF1H473Z 1
34 RESONATOR CERA CR1 KBR-4.0MSTF 5PKBR40MKS 1
35 LED LED101 DLSR-302D(5.5) DDLSR302D1 1
35 WIRE FLAT WF1 1.25X15X90XCWH WSJ-159007 1
37 SW TACT SW102 ~ 105 KPT-1115AM 5S50101Z93 4
38 SW ROTARY SW101 SDB161PVB17F123636 5S10109002 1
39 SW RELAY RY1 G5G-1A DC24V 5SC0101122 1
40 SW RELAY RY2 OJ-SS 124LM 5SC0101405 1
41 VR ROTARY VR101 RP09PV 5V1104103B 1
42 IC MICOM IC1 HD404318E08S 147S636T00 1
43 PCB MAIN M163 M163 3514321120 1
44 PCB SUB M164 M164 3514321210 1
