EXPLODED VIEW AND PARTS LIST
(1) KOR-636T1S
REF NO PART CODE PART NAME DESCRIPTION Q'TY
A00 3511710380 DOOR AS KOR-636T1S 1
B00 3516720960 CONTROL PANEL AS KOR-636T1S 1
F01 3510801310 CABINET PCM T0.36 GE 1
F02 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 3
F03 3516109000 CAVITY WELD AS CAVITY WELD AS 1
3516109600 CAVITY JOINT AS CAVITY WELD AS 1
F04 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 1
F05 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1
F06 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1
F07 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 2
F08 35113AEQ0D CORD POWER AS 3X0.75 70X70 100-RTML 1
F09 4413A90012 CLAMP POWER CORD NYLON66 1
F10 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 1
F11 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1
F12 4415D67620 FUSE 250V 12A 65TS 1
4415D67120 FUSE 250V 12A MDA 1
F13 3518606200 NOISE-FILTER DWLF-M12 1
F14 7121403011 SCREW TAPPING T2S PAN 4X30 MFZN 2
F15 3963513100 MOTOR SHADED POLE 230V 17W OEM-10DWC2-A07 1
3963512310 MOTOR SHADED POLE 230V 20W MW10CA-M02 1
F16 3512517000 GUIDE WIND PP 1
F17 3511800300 FAN PP+30%GLASS 1
F18 3518002200 MAGNETRON 2M218H(MF)I 1
F19 3516004000 SPECIAL SCREW T2 BOLT FLANGE 5X12 DACRO 1
F20 7S422X4081 SPECIAL SCREW TT2 TRS 4*8 SE MFZN 1
F21 3513003200 HOLDER HV CAPACITOR SECC T0.6 1
F22 3518302200 CAPACITOR HV 2100VAC 0.98uF #187 1
F23 3518400400 DIODE HV HVR-1X-3AB 12KV #187 1
F24 3518701100 FUSE HV 5KV 0.55A HV-41A55-02 1
F25 3518115300 TRANS HV DW-N85S0-63T 1
F26 3516003700 SPECIAL SCREW TT3 HEX 4X8 FLG MFZN 4
F27 3510311700 BASE SBHG T0.8 1
F28 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 5
F29 3512100900 FOOT PP DASF-130 2
F30 7S422X4081 SPECIAL SCREW TT2 TRS 4X8 SE MFZN 1
F31 3515201101 STOPPER HINGE *U SCP-1 T2.5 1
F32 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G 1
F33 4415A66910 SW MICRO VP-531A-OF/SZM-V16-FA-61 1
F34 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G 1
F35 3513702600 LEVER LOCK POM 1
F36 3513811710 LOCK POM 1
F37 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G 1
F38 3513601600 LAMP BL 240V 25W T25 C7A H187 1
F39 7121400611 SCREW TAPPING T2S PAN 4X6 MFZN 1
F40 3966310100 MOTOR SYNCRO 220V 2.5W GM-16-24FD12 1
3966310110 MOTOR SYNCRO 220V 2.5W M2LJ49ZT52 1
F41 3518905300 THERMOSTAT OFF:75 ON:65 H #187 NB 1
F42 3513003400 HOLDER THERMOSTAT PBT 1
F43 3516003700 SPECIAL SCREW TT3 HEX 4X8 FLG MFZN 1
F44 3511406200 COVER WAVE GUIDE HEATPROOF PP 1
F45 3517400620 COUPLER XAREC 1
F46 3514700710 ROLLER TEFLON 3
F47 3512517300 GJIDE ROLLER PP 5113MF6 A353B 1
F48 3517203600 TRAY GLASS 1
