Daewoo Mega 250-V - Adjust Rolling Resistance of Drive Pinion Bearing

S0602170K
Page 78
Axle (ZF AP 420R)
ADJUST ROLLING RESISTANCE OF DRIVE
PINION BEARING
Nominal Value
1. Lay measuring ring over the drive pinion
collar.
NOTE: Configuration and description of
the measuring ring, See Figure 161.
NOTE: See “Special Tools” on page 15.
DK / CK 1.1 - 2.3 Nm
(9.7 - 20.3 in lb)
HK 1.5 - 3.0 Nm
(13.2 - 17.7 in lb)
LK / RK 3.0 - 4.5 Nm
(17.7 - 39.8 in lb)
Figure 160
Figure 161
