REFRIGERANT CIRCULATION
1
2
3
4
5
6
HBOI020L
7
Figure 3
Reference
Number
Description
1 Evaporator
2 Expansion Valve
3 Condenser
4 Condenser Fan
5 Compressor
6 Blower Fan
7 Receiver Dryer
