S0406040K
Page 3
Hydraulic Oil Tank
GENERAL DESCRIPTION
PARTS LIST
SECTION B
SECTION A
AHS3710L
Figure 1
Reference
Number
Description
1 Return Filter
2 By-pass Valve
3 Spring
4 Suction Filter
5 Air Breather
6 Level Gauge
7 Drain Plug
Reference
Number
Description
