NO PART NAME PART CODE SPECS. Q
¡¡flfl
TY
1 PIPE BRUSH 3624402400 PP 1
2 NECK 3628000700 PP 1
3 HOOK 3623100100 PA 2
4 COVER BRUSH 3621405400 PP 1
5 COVER AIR 3621406200 PP 1
6 SHAFT 3624900400 SWRM + MFZN 2
7 ROLLER 3624701000 PA + TPE 2
8 RING E 7402004011 ER-4 MFZN 2
9 CAP ROLLER 3620901500 PA 2
10 LEVER BRUSH 3623700800 ABS 1
11 PLATE BRUSH AS 3624500800 ASSY 1
12 SPRING 3625102600 HSW3 2
13 ROLLER 3624700600 PA + TPE 2
14 PIN 3628200200 SWRM MFZN 2
15 PLATE BRUSH 3624500600 SUS T=0.5 1
16 PICKER LITTER 3627000100 ABS + NYLON 2
17 SCREW TAPPING 7121401411 T2S PAN 4 X 14 MFZN 4
SUCTION BRUSH PARTS LIST
13
:
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
