BODY (DOWN) PARTS LIST
NO PART NAME PART CODE SPECS. Q
¡¡flfl
TY
1 TERMINAL AS 3628701900 TERMINAL£«WIRE (WH) 1
2 TERMINAL AS 3628703100 TERMINAL£«WIRE (BK) 1
3 HARNESS 3622705600 1
4 CEC 4505A63030 ST CE-230 1
5 SCREW TAPPING 7121401011 T2S PAN 4¡¿10 MFZN 2
6 BRACKET CR 3620600300 ABS 1
3620600310 PC
7 SCREW TAPPING 7121401411 T2S PAN 4¡¿14 MFZN 4
8 TERMINAL OB 3628700100 C2600P 1
9 TERMINAL OA 3628700200 C2600P 1
10 BOBBIN 3629200200 ABS 1
11 POWER CORD WKH14N7811 ISRAEL 1
3621301000 KS
4568F38022 CHILE
4569A36010 SEMKO
12 BOBBIN 3629200100 ABS 1
13 REEL SHAFT 4569C35050 ABS 1
14 SPRING REEL AS 3625102000 SUS 301 EH 1
15 SCREW TAPPING 7121300811 T2S PAN 3¡¿8 MFZN 2
16 LEVER CR 3623700700 ABS 1
17 STOPPER CR 4569C35082 NBR 1
18 SPRING CR LEVER 3625102300 HSW3 1
19 STOPPER FRAME 4565A35070 POM 1
20 WAX VASELINE 2291140301
21 COVER BACK CASTER 4569C20070 ABS 2
22 CASTER FRAME BACK 4569C20020 PP 2
23 BRACKET FRONT CASTER 4569C20040 PP 1
24 CASTER FRONT 4568A45020 PP 1
25 CAP MOTOR BACK 4569C10040 NR 1
26 MOTOR SPONGE 4569C10070 POLY URETHANE FOAM 1
27 V/C MOTOR 3962330330 220V, 1200W O/S 1
3962510230 230V, 1200W E-class
3962511300 230V, 1200W F-class
3962610600 240V, 1200W
28 CAP MOTOR FRONT 4569A20040 NR 1
29 BODY EXAUST FILTER 4569C20060 POLYESTER 1
30 SCREW TAPPING 7121402011 T2S PAN 4¡¿20 MFZN 6
31 DA PACKING-R 4569R20080 NR 1
32 PROTECTOR 4569C20030 PVC-S 1
33 BODY 4569C20010 ABS 1
7
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
