RATED VOLTAGE AND RATED FREQUENCY AC 220V / 50Hz
AC 230V / 50Hz
AC 230V / 50, 60Hz
AC 240V / 50 Hz
RATED INPUT 1200W
DIMENSION (W¡¿L¡¿H) 270¡¿482¡¿234(mm)
NET WEIGHT 7.3kg
CORD LENGTH 5m / 6m
CONTENTS
1. SPECIFICATIONS 1
2. CIRCUIT DIAGRAM 2
3. CAUSE OF TROUBLE AND COUNTERMEASURE 3
4.
¡
DESCRIPTION 4
¡
DISCRIPTION LIST 5
5. EXPLODED VIEW AND PARTS LIST 6
¡
BODY (DOWN) ASS’Y 6
¡
BODY (DOWN) PARTS LIST 7
¡
COVER ASS’Y 8
¡
COVER PARTS LIST 9
¡
HOSE LINE ASS’Y 10
¡
HOSE LINE PARTS LIST 11
¡
SUCTION BRUSH ASS’Y 12
¡
SUCTION BRUSH PARTS LIST 13
¡
BOX FILTER ASS’Y 14
¡
BOX FILTER PARTS LIST 14
¡
ACCESSORY NOZZLES 15
¡
ACCESSORY NOZZLES PARTS LIST 15
1
1. SPECIFICATIONS
