Daewoo RC-407 User Manual

2
2. CIRCUIT DIAGRAM
BLUE
BLACK
WHITE
BLUE
BLACK
WHITE
MOTOR
THERMOSTAT
250V 7.5A, 85˚C
SWITCH
250V 10A
POWER CORD
AC 250V, 7A
POWER
C3
104K
C2
104K
FILTER COIL
120µH, 12A
TRIAC
SM16JZ47
R5
100 1W
R4
R3
P.C.B
C1
104K
DIAC
DB4
YELLOW
YELLOW
S/V
R1 R2
LR-03 LP-03
HARNESS ASS'Y
WIRING DIAGRAM
M
WHWH
BK
CR
BK BK
BL
BK WH
WH
YW
SLIDE
VOLUME
T1 T2
PCB ASS'Y
YW
BL
VOLTAGE R1 R2 R3 R4 SLIDE VOLUME THERMOSTAT
AC 110V/50, 60HZ 1KΩ 1/2W 1KΩ 1/2W 91KΩ 1/2W 91KΩ 1/2W 200KΩ 85˚C
AC 220V/50HZ 10KΩ 1/2W 10KΩ 1/2W 180KΩ 1/2W 240KΩ 1/2W 500KΩ 85˚C
AC 220V/60HZ 10KΩ 1/2W 10KΩ 1/2W 150KΩ 1/2W 160KΩ 1/2W 500KΩ 85˚C
AC 230V/50,60HZ 10KΩ 1/2W 10KΩ 1/2W 180KΩ 1/2W 180KΩ 1/2W 500KΩ 85˚C
