COVER PARTS LIST
NO PART NAME PART CODE SPECS. Q
¡¡flfl
TY
1 LATCH PUSH 4519F35000 1
2 COVER NOZZLE 3621405100 ABS 1
3 COVER DM 4560F30040 ABS 1
4 SCREW TAPPING 7121301211 T2S PAN 3X12 MFZN 2
5 VALVE 3625400100 LDPE 1
6 PACKING 3624000400 PVC-S 1
7 HOUSING 4560F23010 SAN 1
8 DUST METER 4560F23030 ABS (RED) 1
9 DUST METER 4560F23060 ABS (GREEN) 1
10 SPRING 3625102500 SUS 1
11 ELBOW DM 4569C23050 PVC-S 1
12 COVER DUST 3621405000 ABS 1
13 CLAMP COVER 3621201000 ABS 1
14 SPRING 3625102400 HSW3 1
15 SOCKET 3629800900 ABS 1
16 PACKING SOCKET 3624000700 TPE 1
17 PLATE 3624500500 ABS 1
18 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN 7
19 COVER BODY 3621404900 ABS 1
20 PCB AS 3624302100 220~240V/50HZ 1
3624302130 230V/50HZ (SEMKO)
3624302150 230V/50, 60HZ
21 SCREW TAPPING 7121401011 T2S PAN 4X10 MFZN 2
22 VR SLIDE 5V2504001B 500K 1
23 LABEL CONTROL 3623505700 PC FILM 1
24 SCREW TAPPING 7121402011 T2S PAN 4X20 MFZN 2
25 SPRING 4569A24030 HSW3 3
26 BUTTON CR 3626601100 ABS 1
27 FRAME BUTTON 3622200300 ABS 1
28 BUTTON SWITCH 3626601200 ABS 1
29 KNOB 3623400300 ABS 1
30 GUIDE KNOB 3622501100 ABS 1
31 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN 4
32 COVER TOP 3621405300 ABS 1
33 SW PUSH 4569A37000 AC 250V/10A 1
34 THERMOSTAT 3629000600 65˚C 250V 7.5V 1
35 HARNESS 3622706200 1
36 SCREW TAPPING 7121301211 T2S PAN 3X12 MFZN 1
9
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
