Daewoo SCAN-200 - 3-2. Select by function

15
System Diagnostic Manual
Check sensor data
01. Accelerator pedal depression ······ 0.0 [%]
02. Battery voltage ····························24.1 [V]
03. Boost pressure ························997 [hPa]
04. Charged air temperature ·········· 28.6 [°C]
05. Faulty cam sensor ································ 0
06. Faulty crank sensor ······························ 0
07. Coolant temperature ················· 25.0 [°C]
08. Normal engine RPM ····························· 1
09. Faulty engine RPM ······························· 0
10. Engine RPM ································0 [rpm]
Fix Un Main
▲,▼
Press
[Enter] key
Press
[Enter]
key
3-2. Select by function
(01) Engine start data
Select sensor data type
DV11 STEP3 engine ECU
1] Select by group
2] Select by function
Select sensor data LID
DV11 STEP3 engine ECU
[01] Engine start data
[02] Injector data
[03] Voltage data
[04] Fuel pressure data
[05] Engine brake data
[06] CAN communication data
[07] Fan clutch data
[08] Data logging
[09] Switch data
[10] Sensor data
Check sensor data
11. Fuel supply pressure ················0.3[MPa]
12. Fuel temperature ······················ 25.5 [°C]
13. Ignition switch ··································[ON]
14. Engine oil pressure ·················· 845 [hpa]
15. Engine oil temperature ············· 27.2 [°C]
16. Vehicle speed ························· 0.0 [km/h]
17. Faulty fuel high-pressure generator ······ 0
18. External fuel supply amount ·· 0.0 [mg/st]
19. Fuel supply amount ··············· 0.0 [mg/st]
20. Heater relay operation ··················· [OFF]
Fix Un Main
▲,▼
Press
[PgDn]
key
Check sensor data
21. Heater lamp operation ··········[INACTIVE]
22. Faulty main relay in ECU ······················ 0
23. Faulty rail pressure regulating valve ····· 0
24. Starting fuel amount ·············· 0.0 [mg/st]
······································································
01. Accelerator pedal depression ······ 0.0 [%]
02. Battery voltage ····························24.1 [V]
03. Boost pressure ························ 997 [hpa]
04. Charged air temperature ·········· 28.4 [°C]
05. Faulty cam sensor ································ 0
Fix Un Main
▲,▼
Press
[PgDn] key
