20L 700W Microwave Oven
Model No. SDA2090
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Door Viewing Window
2. Door Catches
3. Glass Turntable
4. Motor Spindle
5. Turntable Support Ring
1
2
3
4
5
6
7
8
Description of Parts
The door must be fully closed in order for the Microwave to operate. The door
operates a safety interlock mechanism which prevents the unit from operating
whilst the door is open.
WARNING! The waveguide cover (6) should never be removed.
6. Waveguide Cover
7. Control Panel
8. Door Handle
