3. Mechanical Mode (Operate without a cassette
tape)
a. Remove the FRONT LOADING Mechanism from the
DECK Mechanism.
b. Cap the IR LED and pull the FL RACK. This has the
same effect with cassette loading to the deck.
c. If the S/T POLE BASE is loaded, Play mode starts auto-
matically. If you want other function, press the corre-
sponding button.
d. Turn off the poser when the Mechanism is in the desired
position.
4. Adjustment of the position of the TENSION
POLE (Fig. 4.6)
a. Place the Mechanical mode in the play mode. Refer to the
above section “3. Mechanical mode”.
b. Confirm that the TENSION LEVER is aligned with the
datum hole of the MAINBASE.
c. If the requirement “b” is not satisfied, turn the BAND
BRAKE ADJUST CAP clockwise or counterclockwise
until the two datum holes alignes with each other.
MECHANICAL ADJUSTMENT (CONTINUED)
FIg. 4.6 Adjustment of the TENSION POLE
To Next Page
