JIGS AND TOOLS
1. List of Jigs and Tools
FIG.
NO ITEMS MODEL
N O
REMARKS
NTSC: SP MONOSCOPE 7KHz CHECKING OF THE
1 ALIGNMENT TAPE SP COLORBAR 1KHz ! TAPE TRANSPORTING
(EP MONOSCOPE) SYSTEM
PAL/SCAM: SP MONOSCOPE 6KHz
SP COLORBAR 1KHz
(LP MONOSCOPE)
2
CLEANING TAPE
DHC-602V @
CHECKING OF THE TAPE
(DAEWOO) TRANSPORTING SYSTEM
3
CASSETTE TAPE KT-300NV
#
MEASUREMENT OF
(KOKUSAI) KT-300RV REEL TORQUE
4
VHS SPINDLE
TSH-V4 $
MEASUREMENT OF
HEIGHT GAUGE REEL HEIGHT
5
TENTELO METER
T2-H7-UM %
MEASUREMENT OF
(TENTELO) THE BACK TENSION
FAN TYPE MEASUREMENT OF THE
6 TENSION METER BELOW 3KG ^ PRESSING FORCE FOR
THE PINCH ROLLER
7 DENTAL MIRROR &
CHECKING OF THE TAPE
TRANSPORTING SYSTEM
8
+DRIVER *-1 ASSEMBLY,
DISASSEMBLY
ADJUSTMENT DR IVER *-2 AND ADJUSTMENT
