Daewoo Washing Machine - Page 5

ASSY TUB
NO PART NAME PART CODE SPECIFICATION REMARK
T01 TUB 3618815600 PP
T02 DOOR WASH 3611795000 HIPS COLOR OPTION
T03 PULSATOR AS 3619704710 7.5kg COLOR OPTION
T04 SPECIAL SCREW 3616002900 SUS304
T05 GUIDE DOOR 3612507100 PP
T06 DRAIN STRAINER 3619606600 PP
T07 BASE WATER SUPPLY 3610387100 PP COLOR OPTION
T08 FILTER AS 3611904000 PP+ POLYESTER
T09 FILTER OVERFLOW 3611903800 PP
T10 COVER BASKET 3611416000 PP
T11 BOLT SPIN BASKET 4506B19031
T12 PLATE UPPER 3614516900 SPG T1.2
T13 BASKET SPIN 3619102400 SPCE
T14 PLATE UNDER 3614517900 SPG T2..0
T15 FIXTURE SHAFT AS 3612005300
7.0kg
D
14
T16 BELLOWS AS 3616401600 7.5kg
T17 FIXTURE BELLOWS 3612005100 PP
T18 LINK BRAKE 3617801600 PP BAND W6
T19 SPRING COVER 3615109100 SWC
T20 WINDOW SPIN 3615501900 ABS COLOR OPTION
T21 DOOR SPIN 3611794900 HIPS COLOR OPTION
T22 SWITCH COVER 3619001200 15A 220VAC RW-622,250
T23 PLATE T 3614517000 PP COLOR OPTION
T24 COVER INNER 3611416100 PP
T25 PACKING 3614001900 NBR
T26 GEAR HOUSING AS 3617306200 DWM-7510S R=3.3:1
T27 PULLEY PULSATOR 3618405500 FRPP
T28 SPECIAL BOLT 3616008400 M6 SIDE FIXING
T29 PACKING 4509A05032 NR PUMP MODEL
T30 VALVE CAP 4505F06013 PP
T31 SPRING VALVE 4505C06022 SUS304 WR D1.0
T32 ROD VALVE 3618504000 PP
T33 BELLOWS VALVE 4505C06040 NR
T34 INLET JOINT 3617503800 PP
T35 CASE VALVE 3611118200 PP
T36 CAP 3610909800 PP
T37 HOSE OVERFLOW 4506H60611 PE-HD
T38 ELBOW DRAIN 3617101900 PP NON PUMP MODEL
HOSE A 3613217420 PE-LD/EVA, O-SUNG PUMP MODEL
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
