Daewoo XM-113 - Electrical Parts List (Model: XM-113)

Electrical Parts List
LOCATION PART-CODE PART-DESC REMARKPART-DESC REMARK NO PART-NAMENO PART-NAME LOCATION PART-CODE
361
R CARBON FILM
R607~608
RD-AZ683J-
1/6 68K OHM J
421
R CARBON FILM
R831~832
RD-AZ102J-
1/6 1K OHM J
362
R CARBON FILM
R609~610
RD-AZ682J-
1/6 6.8K OHM J
422
R CARBON FILM
R910
RD-AZ103J-
1/6 10K OHM J
363
R CARBON FILM
R611~612
RD-AZ272J-
1/6 2.7K OHM J
423
R CARBON FILM
R911
RD-AZ223J-
1/6 22K OHM J
364
R CARBON FILM
R613~614
RD-AZ102J-
1/6 1K OHM J
424
R CARBON FILM
R912~913
RD-AZ103J-
1/6 10K OHM J
365
R CARBON FILM
R615~616
RD-AZ223J-
1/6 22K OHM J
425
R CARBON FILM
R914
RD-AZ223J-
1/6 22K OHM J
366
R CARBON FILM
R617~618
RD-AZ272J-
1/6 2.7K OHM J
426
R CARBON FILM
R915
RD-AZ473J-
1/6 47K OHM J
367
R CARBON FILM
R619~620
RD-AZ103J-
1/6 10K OHM J
427
R CARBON FILM
R916
RD-AZ103J-
1/6 10K OHM J
368
R CARBON FILM
R621
RD-AZ333J-
1/6 33K OHM J
428
R CARBON FILM
R921
RD-AZ100J-
1/6 10 OHM J
369
R CARBON FILM
R622
RD-AZ105J-
1/6 1M OHM J
429
R CARBON FILM
R922
RD-AZ332J-
1/6 3.3K OHM J
370
R CARBON FILM
R623
RD-AZ683J-
1/6 68K OHM J
430
R CARBON FILM
R923
RD-AZ103J-
1/6 10K OHM J
371
R CARBON FILM
R624
RD-AZ103J-
1/6 10K OHM J
431
R CARBON FILM
R933~934
RD-AZ221J-
1/6 220 OHM J
372
R CARBON FILM
R625~626
RD-AZ184J-
1/6 180K OHM J
432
R CARBON FILM
R939~940
RD-AZ109J-
1/6 1 OHM J
373
R CARBON FILM
R627~628
RD-AZ151J-
1/6 150 OHM J
433
TUNER PACK
TU001
9737613201
KST-F401VA-3
374
R CARBON FILM
R629~630
RD-AZ224J-
1/6 220K OHM J
434
WIRE LEAD
W002
W1-BK11161
1P #26 110MM BK UL 1007
375
R CARBON FILM
R631~632
RD-AZ822J-
1/6 8.2K OHM J
435
WIRE LEAD
W003
W1-RE32161
1P #26 320MM RED UL 1007
376
R CARBON FILM
R633~634
RD-AZ392J-
1/6 3.9K OHM J
436
WIRE LEAD
W004
W1-BK60061
1P #26 60MM BK UL 1007
377
R CARBON FILM
R635~636
RD-AZ561J-
1/6 560 OHM J
437
C DISCRIMINATOR
XC201
5P107MG86C
CDA10.7MG86N-C
378
R CARBON FILM
R637~638
RD-AZ184J-
1/6 180K OHM J
438
X-TAL
XC251
5XA7R2000D
7.2M
379
R CARBON FILM
R639~640
RD-AZ472J-
1/6 4.7K OHM J
439
RESONATOR CERA
XC501
5PCSA16R93
CSA16.93MXZ04
380
R CARBON FILM
R641
RD-AZ103J-
1/6 10K OHM J
1
PANEL FRONT AS
13000
9CDM043800
XM-113
381
R CARBON FILM
R643~644
RD-AZ223J-
1/6 22K OHM J
2
PCB FRONT
B700
9CD6582700-01
247X139X1.6T
382
R CARBON FILM
R645~648
RD-AZ472J-
1/6 4.7K OHM J
3
C CERA
CC701
CCZF1E223Z
HIKF 25V 0.022MF Z (AXIAL)
383
R CARBON FILM
R649
RD-AZ823J-
1/6 82K OHM J
4
C CERA
CC703
CCZF1H104Z
HIKF 50V 0.1MF Z (AXIAL)
384
R CARBON FILM
R650
RD-AZ124J-
1/6 120K OHM J
5
C CERA
CC704~706
CCZF1E223Z
HIKF 25V 0.022MF Z (AXIAL)
385
R CARBON FILM
R651
RD-AZ103J-
1/6 10K OHM J
6
C CERA
CC710
CCZF1H104Z
HIKF 50V 0.1MF Z (AXIAL)
386
R CARBON FILM
R652
RD-AZ479J-
1/6 4.7 OHM J
7
C CERA
CC711
CZCH1H150J
CH 50V 15PF J (AXIAL)
387
R CARBON FILM
R653
RD-AZ473J-
1/6 47K OHM J
8
C CERA
CC712
CZCH1H180J
CH 50V 18PF J (AXIAL)
388
R CARBON FILM
R654
RD-AZ271J-
1/6 270 OHM J
9
C CERA
CC713~714
CZSL1H330J
SL 50V 33PF J (AXIAL)
389
R CARBON FILM
R655
RD-AZ102J-
1/6 1K OHM J
10
C CERA
CC715
CCZF1E223Z
HIKF 25V 0.022MF Z (AXIAL)
390
R CARBON FILM
R656
RD-AZ333J-
1/6 33K OHM J
11
C CERA
CC719
CCZF1E223Z
HIKF 25V 0.022MF Z (AXIAL)
391
R CARBON FILM
R657
RD-AZ470J-
1/6 47 OHM J
12
C CERA
CC722
CCZF1H104Z
HIKF 50V 0.1MF Z (AXIAL)
392
R CARBON FILM
R658
RD-AZ473J-
1/6 47K OHM J
13
C ELECTRO
CE702
CEXF1H229V
50V RSS 2.2MF (5X11) TP
393
R CARBON FILM
R659
RD-AZ102J-
1/6 1K OHM J
14
C ELECTRO
CE704
CEXF1A102V
10V RSS 1000MF (8X12.5) TP
394
R CARBON FILM
R662
RD-AZ103J-
1/6 10K OHM J
15
C ELECTRO
CE705
CEXF1E101V
25V RSS 100MF (6.3X11) TP
395
R CARBON FILM
R663
RD-AZ331J-
1/6 330 OHM J
16
C ELECTRO
CE706
CEXF1H229V
50V RSS 2.2MF (5X11) TP
396
R CARBON FILM
R664
RD-AZ472J-
1/6 4.7K OHM J
17
C ELECTRO
CE708
CEXF1H100V
50V RSS 10MF (5X11) TP
397
WIRE JUMPER
R667
W581GY6095
AWG22 1/0.65 SN 6 AUTO
18
C ELECTRO
CE711
CEXF1H229V
50V RSS 2.2MF (5X11) TP
398
WIRE JUMPER
R668
W581GY6095
AWG22 1/0.65 SN 6 AUTO
19
CONN AS
CN705
9728802700
#26 13P FLAT 250MM P=2.5
399
R CARBON FILM
R669
RD-AZ103J-
1/6 10K OHM J
20
PIN WAFER
CW401
9736407700
52084-1310 13P BOTTOM
400
R CARBON FILM
R670~671
RD-AZ472J-
1/6 4.7K OHM J
21
PIN WAFER
CW402
9736407700
52084-1310 13P BOTTOM
401
R CARBON FILM
R672
RD-AZ101J-
1/6 100 OHM J
22
DIODE
D704
DZN4148---
IN4148 AUTO 52MM
402
R CARBON FILM
R673
RD-AZ105J-
1/6 1M OHM J
23
DIODE
D706~707
DZN4148---
IN4148 AUTO 52MM
403
R CARBON FILM
R674
RD-AZ103J-
1/6 10K OHM J
24
VFD
FD701
DSVA09MS18
HNA-09MS18
404
R CARBON FILM
R675
RD-AZ102J-
1/6 1K OHM J
25
IC
IC701
1M38199278F
U-COM M38199MF-278FP
405
R CARBON FILM
R676
RD-AZ105J-
1/6 1M OHM J
26
IC
IC702
1M24C04---
M24C04-BN6
406
R CARBON FILM
R683
RD-AZ103J-
1/6 10K OHM J
27
IC PRE AMP
IC705
1HEG838---
HEG838
407
R CARBON FILM
R684
RD-AZ392J-
1/6 3.9K OHM J
28
TR
Q701
TZRC107M--
KRC107-M TAPPING(KSR1006)
408
R CARBON FILM
R685~686
RD-AZ102J-
1/6 1K OHM J
29
R CARBON FILM
R351
RD-AZ101J-
1/6 100 OHM J
409
R CARBON FILM
R688
RD-AZ101J-
1/6 100 OHM J
30
R CARBON FILM
R352
RD-AZ151J-
1/6 150 OHM J
410
R CARBON FILM
R696
RD-AZ333J-
1/6 33K OHM J
31
R CARBON FILM
R353
RD-AZ181J-
1/6 180 OHM J
411
R CARBON FILM
R699
RD-AZ102J-
1/6 1K OHM J
32
R CARBON FILM
R354
RD-AZ271J-
1/6 270 OHM J
412
R CARBON FILM
R803~804
RD-AZ102J-
1/6 1K OHM J
33
R CARBON FILM
R355
RD-AZ331J-
1/6 330 OHM J
413
R CARBON FILM
R805~806
RD-AZ563J-
1/6 56K OHM J
34
R CARBON FILM
R356
RD-AZ391J-
1/6 390 OHM J
414
R CARBON FILM
R807~808
RD-AZ821J-
1/6 820 OHM J
35
R CARBON FILM
R357
RD-AZ471J-
1/6 470 OHM J
415
R CARBON FILM
R809~812
RD-4Z100J-
1/4 10 OHM J
36
R CARBON FILM
R358
RD-AZ561J-
1/6 560 OHM J
416
R CARBON FILM
R813
RD-AZ103J-
1/6 10K OHM J
37
R CARBON FILM
R360
RD-AZ101J-
1/6 100 OHM J
417
R CARBON FILM
R815~818
RD-4Z102J-
1/4 1K OHM J
38
R CARBON FILM
R361
RD-AZ151J-
1/6 150 OHM J
418
R CARBON FILM
R821
RD-AZ154J-
1/6 150K OHM J
39
R CARBON FILM
R362
RD-AZ181J-
1/6 180 OHM J
419
R CARBON FILM
R823~824
RD-AZ104J-
1/6 100K OHM J
40
R CARBON FILM
R363
RD-AZ271J-
1/6 270 OHM J
420
R CARBON FILM
R825
RD-AZ103J-
1/6 10K OHM J
41
R CARBON FILM
R364
RD-AZ331J-
1/6 330 OHM J
Electrical Parts List
25
MODEL : XM-113
