Daewoo XM-113 - Electrical Parts List (Model: XM-113)

Electrical Parts List
PART-DESC REMARKNO PART-NAME LOCATION PART-CODE
42
R CARBON FILM
R365
RD-AZ391J-
1/6 390 OHM J
43
R CARBON FILM
R366
RD-AZ471J-
1/6 470 OHM J
44
R CARBON FILM
R367
RD-AZ561J-
1/6 560 OHM J
45
R CARBON FILM
R368
RD-AZ821J-
1/6 820 OHM J
46
R CARBON FILM
R369
RD-AZ101J-
1/6 100 OHM J
47
R CARBON FILM
R370
RD-AZ151J-
1/6 150 OHM J
48
R CARBON FILM
R371
RD-AZ821J-
1/6 820 OHM J
49
R CARBON FILM
R381
RD-AZ392J-
1/6 3.9K OHM J
50
R CARBON FILM
R701~702
RD-AZ103J-
1/6 10K OHM J
51
R CARBON FILM
R707
RD-AZ103J-
1/6 10K OHM J
52
R CARBON FILM
R719~721
RD-AZ152J-
1/6 1.5K OHM J
53
R CARBON FILM
R722
RD-AZ472J-
1/6 4.7K OHM J
54
R CARBON FILM
R724
RD-AZ103J-
1/6 10K OHM J
55
R CARBON FILM
R751
RD-AZ472J-
1/6 4.7K OHM J
56
R CARBON FILM
R759
RD-AZ106J-
1/6 10M OHM J
57
R CARBON FILM
R760
RD-AZ334J-
1/6 330K OHM J
58
R CARBON FILM
R761
RD-AZ101J-
1/6 100 OHM J
59
R CARBON FILM
R762
RD-AZ100J-
1/6 10 OHM J
60
R CARBON FILM
R770
RD-AZ683J-
1/6 68K OHM J
61
R CARBON FILM
R773
RD-AZ103J-
1/6 10K OHM J
62
R CARBON FILM
R775
RD-AZ103J-
1/6 10K OHM J
63
R CARBON FILM
R776
RD-AZ334J-
1/6 330K OHM J
64
R CARBON FILM
R777~778
RD-AZ104J-
1/6 100K OHM J
65
R CARBON FILM
R779
RD-AZ334J-
1/6 330K OHM J
66
R CARBON FILM
R783
RD-AZ223J-
1/6 22K OHM J
67
R CARBON FILM
R784
RD-AZ683J-
1/6 68K OHM J
68
R CARBON FILM
R785
RD-AZ122J-
1/6 1.2K OHM J
69
R CARBON FILM
R785A
RD-AZ104J-
1/6 100K OHM J
70
SW TACT
SW702~709
5S50101001
KPT-1105A 1C-1P
71
SW TACT
SW711~724
5S50101001
KPT-1105A 1C-1P
72
RESONATOR
XC701
5PCSA8MTZ-
CSA8MTZ, 8MHZ
73
X-TAL
XC702
5XA32R768-
DT-38 32.768KHZ 20PPM
1
PCB POWER AS
12000
9CDC055610
AMI-326LV
2
PCB POWER
B991
9CD6582000
98X123
3
CONN AS
CN991
9738833900
#22 8P BOARD-IN 350MM
4
CLIP FUSE
FC901~904
9734600700
FC-5N
5
FUSE GLASS TUBE
F901
5F1GB1622M
UL/CSA NM 1.6A 250V MF51
6
FUSE GLASS TUBE
F902
5FSGB8012L
SEMKO TL 800mA 250V MF51
7
R METAL FILM
R991
RN-2Y475J-
1/2 4.7M OHM J
8
SW VOLTAGE SELE
SW991
5S30102361
SDKHA2-P 1C2P
9
PIN WRAPPING
TP991~992
9716404000
MFZN1.1X1.1 PANASERT
10
CORD AC
CD991
9736908900
1T1OS2
11
TRANS POWER
PT991
5TP0066804
EI=66X45,115/230V,60/50Hz
12
CONN AS
CN501
9738840800
FFC 16P P1.0X250MM R
13
CONN AS
CN605
9738834700
UL 1007 #26 1P 120MM
Electrical Parts List
26
MODEL : XM-113
