EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
3-2
©
200515
Inspection and adjustment
5
ΛΦ45/55 series
3.3 CHECKING THE BATTERY TERMINALS
1. Visually check the battery terminals for
corrosion. Clean the battery terminals if
necessary, see chapter "Cleaning".
2. Check the attachment of the battery
terminals.
3.4 CHECKING THE FLUID LEVEL OF THE CAB TILTING PUMP
1. Check the fluid level when the cab is in the
driving position.
2. The cock (3) should be in the "" position
(clockwise).
3. Loosen the filler plug (1) 3 to 4 turns and wait
until any overpressure has left the reservoir.
Then remove the filler plug (1) and check the
sealing ring (2), replace if necessary.
4. Start pumping with a maximum of five pump
strokes, making sure that the pump lever is in
the bottom position when finished.
5. Then check the fluid level. This level should
be no more than 2 cm below the top of the
filling opening. Top up if necessary.
6. Fit the filler plug (1) and hand tighten it.
G0 00 208
K1 01 181
1
2
3
