(7)
being slightly
twisted.
(Fig.
2)
(5)
Screw indicator
coupling con-
neclor into the
coupling
nut.
(Fie.2)
(6)
lnsert
cable
into
the cable
anchor
bolt.
(Fig.
2, 4)
Cable
adiustment: While turn-
ing
pedals,
move trigger
lever
to "normal"
(No.
2)
position.
Next, loosen
indicator coupling
locknut
and
adlust coupling
nut
until the end
of
the coupl-
ing
rod is 1132 inch
(0.8mm)
aside the
extreme
end of the
axle. This can
be seen through
the
"window"
of the
guide
nut.
(Fig.
3)
Final
adiustment:
(A)
While
turning
pedals pull
the
trigger lever
to
position
No. 1.
lf it
is
hard to set trigger lever at
position
No. 1,
loosen
the
coupling
nut
slightly until
you
can.
Caution should
be taken
not
to loosen
the
nut
too much.
(B)
When the
lever
is
positioned
at
position
No. 1,
if
there
is
excessive
stack in the
cabte, adiust
tlre
coupling nut until
the eaAl€
is
right.
(C)
After checking
that the shifter
is
working properly
in
all three speeds,
secure
the coupling nut
by tightening
it
down
with rhe
indicator
coupling
locknut.
The
hub
should
be lubricated with
two
or
three
drops
of
SAE 20 oil
once
a
montn.
lf
the cable
becomes
frayed
or
broken,
it
should be
replaced
by
a
prcfes-
sional bicvcle dealer.
Always
be certain that
all
parts
are
properly
tightened, and
that worn,
cracked or broken
parts
are replaced
at
once.
6.3.12
Wheels
(Including
Spokes and
Rims)
A.
Disassembly
To
remove
the
front
wheel,
turn the
bicycle upside down,
remove the outer
nuts
(W-1
25)
and
safety washers (W-120)
on
both
sides
of
the
axle, carefully
spread the
fork
blades
out,
and remove
the wheel.
(8)
Fs
3
33
34
To remove the
rear wheel,
put
the
gear
shift lever
(T
810) in middle
(#2)
position.
Check
the cabfe
adlustment as shown in Sec.6.3.13. Tighten
the cable
locknut.
Then,
without
disturbing
the locknut
position,
completely unscrew
the
t,.
aolusung sleeve.
Loosen
the
rear wheel nuts
(W-222
andW-223). Note
the
position
of the
flats on
the
rear
axle in the slots.
The
rear wheel can now be
slid
downward and
outward
from
the
frame.
Note:
lt
may
be
necessary to
remove
one
caliper brake shoe
(see
Scc. 6.3.2)
-'6efore
the tire
will move out
between the
brake
shoes.
o@t
w222
w\25
/
B. Adfustrnent,
Trouble Shooting
and Maintenance
When
replacing
the
wheels, they
should be carefully
centered
between
the
forks and
brakes. Be
certain
that
wheel
nuts are
replaced while
all spokes
should
be adequately
tightened.
When
the
gear
shift
operating
cable connector is
re-
assemblcd, recheck
its setting
as described
in
Sec.
6.3.1 3.
Wheels
should be
regularly
checked
for
"wobbling"
from
side
to side, and
"hop"-
being out of
round
or
of
unequal diameters.This misalignment
can
be
detected bcst
by turning the
bicycle
upside down,
rotating
the
wheel while
using our
finger
or
a
pencil placed
next
to
the rim as
a
guide.
Severe
misalign-
ment will
causc the tire
to
intermittently
rub
against the fork,
or
the rim against
the
brake shoe.
Warning: Whccl
misalignment
will lead
to
grabbing
or failure of braking
power,
and
should be
corrected
at
once.
To
correct this
problem,
first
check the
rim
to make sure it is
not dented or
twisted. lf it is, take
the
wheel
to a
dealer for
specialized repair or
replacement.
Uneven spoke tension,
or
missing, bent
or
broken spokes,
will
also cause
the
