Handlebar adjustment
Seatpost and saddle adjustment
Adjustment of the brakes and derailleur
(1) Loosen the handlepost quick release and adjust the handlepost to an
appropriate height (the safety scale line must not be exposed outside the
tube), and then lock the handle.
(2) Loosen the stem handle and adjust the handlebar to a proper angle.
(1) Loosen the seatpost clamp and adjust the seatpost to an appropriate height
(the safety line should not be visible outside of the pedelec )
(2) Loosen the locking bolt at the bottom of the saddle, adjust the saddle to an
appropriate angle and tighten the bolt (recommended force moment is 18N•m).
(1) Brake adjustment:
Safety line
Safe position
In the case of improper adjustment of brakes, or serious wearing of brake
pads, it will pose a threat to the safety of riders. Please adjust or replace
relevant accessories on time. The brake on the wheel rim of a pedelec
functions via friction between the brake surfaces. The brake structure
depends on the friction between the brake pad and the wheel rim or disc to
ensure maximum friction. Please keep rims or discs and brake pads clean,
free of dirt, lubricants, waxes or polishing agents that may reduce the
efficiency of friction. The brake is designed to control the speed of the bike,
not just to stop it. Brake pads are fragile parts. Please adjust the brake and
brake pads properly according to wear and conditions.
09
