Final Check
Folding & Unfolding
After completion of assembly, please perform a final check and make sure that:
1. Every bolt and screw is tightened properly.
2. Tires are inflated to the recommended tire pressure.
3. Brakes are functioning properly.
Note:
1. Fold your DAHON E-bike according to the manual.
2. When folding and unfolding please take care to check that
the internal cables are not caught. Should this occur, simply
push the two cables back inside the frame.
Folding:
(1) Adjust seatpost and crank: loosen seatpost clamp lever, lower the seatpost,
then lock the seatpost clamp, and adjust the left crank to 9 o'clock position.
(2) Folding the handlebar assembly: loosen the safety catch on the stem, pull the
stem hinge handle down, and then fold the stem down to align the whole
handlebar parallel to the front wheel.
(3) Folding the frame: open the frame safety hook, open the frame hinge lever, put
your knees against the frame folding joint, and bring the front and rear wheels
of the pedelec backward to make the front and rear wheels merge and align
parallel.
(4) Please be aware: Do not fold the bike when the battery is removed for charging.
Unfolding:
Reverse the operation sequence from back to front (expand the frame → lift the
folding stem→ raise the seatpost to an appropriate height → tighten relevant
latches and safety hook) to achieve full unfolding.
Lower the seatpost Fold down the stem Fold the frame in half
08
