1 Introduction
1.1 Appearance
This manual is available for the following appearances.
Figure 1-1 Available appearances
1.2 Cable
Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and
water damage. For the detailed operation, see FAQ manual.
Figure 1-2 Cables
Table 1-1 Cable information
No.
Port name Description
1 Power input
Inputs 12 VDC power. Be sure to supply power as instructed in
the manual.
Device abnormity or damage might occur if power is not
supplied correctly.
2 Ethernet port
Connects to network with network cable.
Provides power to the device with PoE.
PoE is available on select models.
3 Alarm I/O
Includes alarm signal input and output ports. The number of I/O
ports might vary on dierent devices. For detailed information,
see Table 1-2 .
Quick Start Guide
1
