User’s Manual
194
(right to left), and
.
Target Filter
Click to draw areas to filter the target.
You can configure two filtering targets (maximum size and minimum size).
When the target that is crossing the tripwire is smaller than the minimum
size or larger than the maximum size, no alarms will be activated. The
maximum size should be larger than the minimum size.
Preset In the
list, select the preset that you want to configure the rule for.
4) Drag to draw a tripwire. The tripwire can be a straight line, broken line or polygon.
5) Click
OK to save the settings.
Click to set the actions to be triggered.
Trigger
Configure the triggering parameters.
Table 5-47 Trigger parameters
Schedule
Click
to display set interface.
Define a period during which the alarm linkage is active. For details, see
"Setting Motion Detection Period” section in "5.10.4.1 Configuring
Motion Detection Settings."
