Adding Zones
After you’ve entered the “zone” menu. You’ll see the following parts:
ID: This is the id of zones, you can set any number between 0~2048.
Name: This is the name of zones, you can set any name with characters and digital numbers.
Type: This is the type, you can choose DVR, NVR, SD, etc.
Link: This is the connection type, you can choose NET, COM232, COM485.
Link type: NET
IP Addr: IP of the device
Port: Port of the device
Rule: Control protocol “DH-2”
PW: Password for admin account
of the device
Link type: COM232
232 Addr: RS232 address of device
Rule: Control protocol
Baud Rate:
Databit:
Parity:
Stop Bit:
Link type: COM485
485 Addr:
Rule:
Baud Rate:
Databit:
Parity:
Stopbit:
Based on the link type, you’ll have 3 different configurations as follows:
