Dahua EEC300D8-N1 - Appearance of Data Collection Modules

4
No. Name Description
9 Connector.
Transfers the data from control module and data collection
modules
10
Heat dissipation
hole
—
11 Ports
Include power input port, USB ports, Ethernet ports, and RS-232
port. For details, see Table 1-2.
1.2.2 Appearance of Data Collection Modules
Appearance of data collection modules Figure 1-3
