Dahua IPC-HFW2300R-Z User Manual

1
1 Framework
1.1 Device External Cable
You can refer to the following figure for device external cable information. See Figure 1-1.
Figure 1-1
Please refer to the following sheet for detailed information.
SN
Port
Port Name
Connection
Note
1
LAN
Network port
Ethernet
port
Connect to standard Ethernet cable.
Note:
Before making crystal head, pull the
anti-dust cover (default), waterproof
cover (optional) through network
cable.
2
DC 12V
Power input
port
-
Power port. Input DC 12V.

Dahua IPC-HFW2300R-Z Specifications

General

Brand	Dahua
Model	IPC-HFW2300R-Z
Category	Security Camera
Language	English
