Dahua NVR4204-P-4KS2 User Manual

119
Figure 2-69
The NVR41HS-P-4KS2 series rear panel is shown as below. See Figure 2-70.
Figure 2-70
The NVR41HS-8P-4KS2 series rear panel is shown as below. See Figure 2-71
Figure 2-71
Please refer to the following sheet for detailed information.
Port Name
Connection
Function
USB port
USB port. Connect to mouse, USB storage device, USB
burner and etc.
/
Power input port
Power socket.
For NVR41HS-4KS2: DC 12V/2A power.
For NVR41HS-P-4KS2: DC 48V/72W power.
For NVR41HS-8P-4KS2: DC 48V/96W power.
Network port
10M/100Mbps self-adaptive Ethernet port. Connect to the
network cable.
USB port
USB port. Connect to mouse, USB storage device and
etc.
HDMI
High Definition
Media Interface
High definition audio and video signal output port. It
transmits uncompressed high definition video and
multiple-channel data to the HDMI port of the display
device. HDMI version is 1.4.
