1 Installation Preparation
1.1 Basic Requirements
●
All installation and operations shall conform to your local electrical safety regulations, re
protection regulations, and other relevant regulations.
●
Make sure that the application scenario conforms to installation requirements. Contact your
local retailer or customer service center if there is any problem.
●
Use the Device according to the operating environment.
●
Keep the original packing material well because you might need it to pack the Device and send
it back for repair.
1.2 Installation Check
●
Make sure that the place where the Device is installed has enough space to hold the Device and
its mounting accessories.
●
For PTZ cameras, make sure that the place where the Device is installed can sustain at least 4
times the weight of the Device and its mounting accessories; for speed domes, make sure that
the ceiling and wall can sustain 8 times the weight of the Device and its mounting accessories.
●
Do not install the Device at risky or unstable places.
●
Make sure that the wall is thick enough to install expansion bolts (Users need to buy expansion
bolts separately).
●
For speed domes support intelligent tracking, illegal parking capture or laser, make sure that the
mounting height is over 6 m.
●
For laser PTZ, make sure that the mounting height is over 10 m.
●
Support wall mount and plane mount, xed with M8 × 25 hex ange assembling bolts.
1.3 Cable Preparation
Select the video cable depending on transmission distance.
1.3.1 Video Cable Requirements
●
75 ohm.
●
Pure copper cored cables.
●
95% braided copper shielding.
Table 1-1 Cables and maximum transmission distance (network)
Model
Maximum Transmission Distance (ft/m)
RG59/U 750 ft/229 m
RG6/U 1,000 ft/305 m
RG11/U 1,500 ft/457 m
1
